4K@60HZ HDMI Extender 60M With Loopout & Dual IR 【JC-EX608H】

4K@60HZ HDMI Extender 60M With Loopout & Dual IR

【JC-EX607H】







Parameter

Description

Video

Standards

HDMI2.0; HDCP 2.2

Maximum pixel clock

340MHz

Maximum data rate

18Gbps

Maximum resolution

3840*2160@60Hz (backward-compatible)

Connector

HDMI-A

Impedance

100Ω

IR

Interface

3.5mm earphone seat

Signal direction

Bi-directional

Signal type

Digital

IR frequency

20-60kHz

UTP

Interface

RJ45 (IEEE - 568b connection)

Transmission distance

CAT6-60M

Other

Power supply

The power adapter: DC 5V/1A

Power dissipation

MAX 3W

Temperature

Operating: -5℃ ~ +70℃

Humidity

Operating: 5% ~ 90%

Dimension

82*65*17mm

The warranty

1 year free warranty

Receiver
