4K@30HZ HDMI Extender 120M With Loopout & Dual IR 【JC-EX607H】

4K@30HZ HDMI Extender 120M With Loopout & Dual IR

【JC-EX607H】



Parameter

Description

Video

Standards

HDMI1.4; HDCP 1.4

Maximum pixel clock

225MHz

Maximum data rate

10.2Gbps

Maximum resolution

3840*2160@30Hz (backward-compatible

Connector

HDMI-A

Impedance

100Ω

USB

Interface

PC: Standard USB-A

K/M: Standard USB-A

USB Signal

HID Signal

UTP

Interface

RJ45 (IEEE - 568b connection)

Transmission distance

CAT6-120M

Other

Power supply

The power adapter: DC 5V

Power dissipation

MAX 4W

Temperature

Operating: -5~ +70

Humidity

Operating: 5% ~ 90%

Dimension

82*85*17mm

The warranty

1 year free warranty





Receiver
