JC-EF305HK Digital Full HD HDMI KVM Fiber Extender 20KM with Loopout and IR
Digital Full HD HDMI KVM Fiber Extender 20KM
with Loopout and IR
Model NO.: JC-EF305HK
|
Parameter |
Description |
|
|
Video |
Standards |
HDMI 1.3, HDCP 1.2 |
|
Maximum Pixel Clock |
165MHz |
|
|
Maximum Data Rate |
6.75Gbps |
|
|
Resolution Range |
Max: 1920X1080@60Hz |
|
|
Connector |
Female HDMI Type A |
|
|
Impedance |
100Ω |
|
|
K/M |
Connector |
USB-A |
|
Signal |
USB HID |
|
|
Infrared |
Interface |
3.5mm Earphone Seat |
|
Signal Type |
Digital |
|
|
Transmission Direction |
Unidirectional |
|
|
Carrier Frequency |
38kHz |
|
|
Optical Fiber |
Interface |
FC connector |
|
Fiber Type |
Single Mode |
|
|
Wavelength |
TX 1310nm; RX 1550nm |
|
|
Interface Bandwidth |
155Mbps |
|
|
|
Transmission Distance |
Standard: 20km |
|
Other |
Power Supply |
The Power Adapter: DC 5V/2A |
|
Power Dissipation |
Max: 5W |
|
|
Temperature |
Operating: -5℃ ~ +70℃ |
|
|
Humidity |
Operating: 5% ~ 90% |
|
|
Dimension |
100*97.5*18.6mm |
|
