4K HDMI KVM Fiber Optic Extender 2-80km with Loopout and RS232 +EDID fucntion【JC-EF301HK】

EF301HK-2







Parameter

Description

Video

Standards

HDMI 1.4, HDCP 1.4

Maximum Pixel Clock

225MHz

Maximum Data Rate

10Gbps

Resolution Range

3840X2160@30Hz;  1920*1200@60Hz ; 1920*1080@60Hz  1920*1080@50Hz ; 1920*1080@30Hz  1920*1080@25Hz ; 1920*1080@24Hz

1080I@60Hz ; 1080I@50Hz

1280*720@60Hz ; 1280*720@50Hz

Connector

Female HDMI Type A

Impedance

100Ω

K/M

Connector

USB-A

Signal

USB HID

Optical Fiber

Interface

LC connector

Fiber Type

Single Mode

Wavelength

1310nm

Interface Bandwidth

10.2Gbps

Other

Transmission Distance

Standard: 2km (10-80km optional

Power Supply

The Power Adapter: DC 12V

Power Dissipation

Max: 5W

Temperature

Operating: -5~ +70

Humidity

Operating: 5% ~ 90%

Dimension

133*90*26mm



产品展示

JC-EF301HK
EF301HK-2
EF301HK-TX
EF301HK-RX
