【JC-EX606H】 H.265 4K HDMI Extender Over IP Support loopout + RS232 + Audio
H.265 4K HDMI Extender Over IP
NO：JC-EX606H
|
Parameter |
Description |
|
|
Video |
protocol |
HDMI 1.4; HDCP 1.4 |
|
Maximum pixel clock |
225MHz，digital |
|
|
Maximum data rate |
10.2Gbps |
|
|
Highest resolution |
3840X2160@30Hz and Backward compatible |
|
|
Connector |
HDMI-A |
|
|
HDMI Impedance |
100Ω |
|
|
HDMI cable |
Less than 5meters ；24AWG |
|
|
RS232 |
Port |
DB9 |
|
Signal direction |
Two-way transmission |
|
|
Baud rate |
115200bps (Other baud rates need to be set on the web) |
|
|
Data bit |
8 bits |
|
|
Audio |
Port |
3.5mm Stereo audio socket |
|
Audio format |
44.1K,48K,96K,176K,192K |
|
|
Signal type |
Stereo audio |
|
|
IR |
Interface |
3.5mm earphone seat |
|
Signal direction |
Unidirectional pass-back |
|
|
Signal type |
Digital |
|
|
IR frequency |
38kHz |
|
|
Ethernet port |
Connector |
RJ45 port（568B） |
|
Longest distance |
120metres via cat6; 70m via cat5e |
|
|
Others |
Power supply |
Adapter：DC 5V/2A |
|
Others |
Power dissipation |
MAX 6W |
|
Temperature |
-5℃ ~ +70℃ |
|
|
Humidity |
5% ~ 90% |
|
|
Dimension |
134*93*24mm |
|
|
The warranty |
2 years warranty |
Point to Point
Point to multi-point
