4K@60HZ HDMI KVM Extender 60M With Loopout 【JC-EX608HK】
4K@60HZ HDMI KVM Extender 60M With Loopout
【JC-EX608HK】
|
Parameter |
Description |
|
|
Video |
Standards |
HDMI2.0; HDCP 2.2 |
|
Maximum pixel clock |
340MHz |
|
|
Maximum data rate |
18Gbps |
|
|
Maximum resolution |
3840*2160@60Hz （backward-compatible） |
|
|
Connector |
HDMI-A |
|
|
Impedance |
100Ω |
|
|
USB |
Interface |
PC: Standard USB-A K/M: Standard USB-A |
|
USB Signal |
HID Signal |
|
|
UTP |
Interface |
RJ45 (IEEE - 568b connection) |
|
Transmission distance |
CAT6-60M |
|
|
Other |
Power supply |
The power adapter: DC 5V |
|
Power dissipation |
MAX 4W |
|
|
Temperature |
Operating: -5℃ ~ +70℃ |
|
|
Humidity |
Operating: 5% ~ 90% |
|
|
Dimension |
82*85*17mm |
|
|
The warranty |
1 year free warranty |
|
Receiver
